MATCHFIT Dovetail (14° x 1/2") Router Bit (1/4" Shank)

MB-025-0514

Regular price $35.30
/

MATCHFIT Dovetail (14° x 1/2") Router Bit (1/4" Shank)

Route silky smooth dovetail tracks in a single pass.

Specially designed to route tracks for MATCHFIT Dovetail Clamps and Dovetail Hardware. The Dovetail Bit's built-in roundovers cut clean dovetail grooves in a single pass.  Less time sanding, more time building. Available in 1/2", 1/4", 12mm, and 8mm shank sizes.

One dovetail bit. One pass.

  • Router collet safety line prevents bit from bottoming out in the router.
  • Laser etched depth guide allows you to dial in cutting depth in a snap.
  • The built-in 1/16” roundover smooths out the top shoulders of the groove to prevent material from binding.
  • The built-in 1/32” roundover strengthens the groove walls and helps clamps and hardware move more smoothly.

Route T-tracks virtually anywhere.

MATCHFIT Dovetail Router Bit (1/2"-14°)
  • ½” 14-degree dovetail profileLaser etched depth guide to quickly set cutting depth.
  • Laser etched depth guide to quickly set cutting depth. Depth tolerance: .365-.395”
  • Built in roundovers for smoother cuts and less sanding.
MATCHFIT Dovetail Router Bit (1/2"-14°)
  • Extra wide shoulder reduces vibration and noise.
  • 8-degree downshear carbide reduces splintering and contains dust.
  • Available in 1/2", 1/4", 12mm, and 8mm shank sizes.
