Product Features

• Powerful 1 HP, 120V heavy-duty TEFC motor and solid construction to effectively handle the collection of wood chips and sawdust
• 700 CFM air suction capacity
• Aluminum impeller is precision balanced and designed for maximum air flow performance
• Paddle switch with removable safety key
• Washable 1 Micron upper felt dust bag for optimal air flow efficiency and reusable clear plastic lower dust bags (3)
• Sturdy base with 4 swivel casters and handle for maneuverability
• 4” diameter inlet port

Product Features

• 1,200 CFM dust collector with canister filter
• 1 Mcron canister filter, offering optimum air flow efficiency
• Heavy-duty motor and solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• Lower plastic see-through bag
• Can be operated at 110V or 220V
• Switch with removable safety key
• 4” diameter dust ports accept accessory hoses for attaching up to 2 machines

Silent operating dust collector for wood dust applications

The S-Series dust collector is an enclosure-less, silent and simple to setup dust collector for your wood dust collection needs. Ideal for indoor installation, the S-Series is available in three sizes, the S-500, S-750 and S-1000 with an operating capacity of up to 5000 CFM. The fan operates at a low rpm resulting in quieter operation compared to competing indoor dust collection systems. It is equipped with the Super Bag filter which is safe for use with wood dust and is 99% efficient.

• Silent operation
• Safe for indoor installation
• Simple setup
• Simple maintenance

Silent operating dust collector for wood dust applications

The S-Series dust collector is an enclosure-less, silent and simple to setup dust collector for your wood dust collection needs. Ideal for indoor installation, the S-Series is available in three sizes, the S-500, S-750 and S-1000 with an operating capacity of up to 5000 CFM. The fan operates at a low rpm resulting in quieter operation compared to competing indoor dust collection systems. It is equipped with the Super Bag filter which is safe for use with wood dust and is 99% efficient.

• Silent operation
• Safe for indoor installation
• Simple setup
• Simple maintenance

Silent operating dust collector for wood dust applications

The S-Series dust collector is an enclosure-less, silent and simple to setup dust collector for your wood dust collection needs. Ideal for indoor installation, the S-Series is available in three sizes, the S-500, S-750 and S-1000 with an operating capacity of up to 5000 CFM. The fan operates at a low rpm resulting in quieter operation compared to competing indoor dust collection systems. It is equipped with the Super Bag filter which is safe for use with wood dust and is 99% efficient.

• Silent operation
• Safe for indoor installation
• Simple setup
• Simple maintenance

Product Features

• 1,200 CFM dust collector with canister filter
• 1 Micron canister filter, offering optimum air flow efficiency
• Heavy-duty motor and solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• Lower plastic see-through bag
• Switch with removable safety key
• 4” diameter dust ports accept accessory hoses for attaching up to 2 machines

Product Features

• Heavy duty 1 HP motor and solid construction effectively handles the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• Complete with 4 wheel castors for portability
• 4” diameter dust port
• Comes complete with dust bag, 4” x 10’ flexible hose and wide dust hood, which mounts on the arm support

Product Features

• 2,280 CFM dust collector with canister filter
• 1 Micron canister filter, offering optimum air flow effeciency
• Heavy-duty motor and solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• 14” impellor
• Lower plastic see-through bags
• Switch with removable safety key
• 4” diameter dust ports accept accessory hoses for attaching up to  3 machines

Product Features

• 3,980 CFM dust collector
• Heavy duty motor and solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• Complete with 4 wheel castors for portability
• Lower collection cloth bags come with see-through window
• 4” diameter dust ports accept accessory hoses for attaching up to 4 machines

Product Features

• 1,200 CFM dust collector
• Heavy duty motor and solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• Switch with removable safety key
• Lower plastic see-through bag
• 1 Micron felt upper bag, offering optimum air flow efficiency
• 4” diameter dust ports accept accessory hoses for attaching up to 2 machines

Product Features

• 2,280 CFM dust collector
• Heavy duty motor and  solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• 14” impellor
• Complete with 4 wheel castors for portability
• Lower plastic see-through bags
• 1 Micron felt upper bags, offering optimum air flow efficiency
• 4” diameter dust ports accept accessory hoses for attaching up to 3 machines

Product Features

• 1,200 CFM dust collector

• Heavy duty motor and solid construction to effectively handle the collection of wood chips and sawdust
• Improved metal impellers are precision balanced and designed for maximum air flow performance
• Can be operated at 110V or 220V
• Switch with removable safety key
• Lower plastic see-through bag
• 1 Micron felt upper bag, offering optimum air flow efficiency
• 4” diameter dust ports accept accessory hoses for attaching up to 2 machines

• Motor HP: 2 HP
• Phase: 1
• Voltage: 220v
• Amps: 18.8 Amps
• Hertz: 60
• Plug: No
• RPM: 3450
• Switch type: Radio Frequency Remote switch – Black Box
• Hand held remote control: HF
• Real CFM: 1166
• Nominal CFM: 1740
• Max Static Pressure (inches of water): 9.3?
• Impeller/Fan Size: 14.5?
• Impeller Material: Steel
• Impeller type: Radial Fin
• Balanced To:: ISO 1940
• Inlet Diameters: 6? by 4? x 2 ports
• Drum Capacity: 46 Gal.
• Octagon drum: Metal drum insert
• Drum collection bag (Dia. x L): Plastic bag (610 x 950mmL)
• Canister Filter type: 1 Micron
• Filtration efficiency: 0.2-2micron @ 99.97%
• MERV rating: 12
• Canister diameter: 400mm (15.75?)
• Cansiter length: 900mm (19.69?)
• Filter Surface Area: 9.5m²/109ft²
• Canister cleaning: Manual Handle Crank/*Optional Auto Cleaning Kit available
• Canister filter lower dust collection: Plastic bag (400 x 600mmL)
• Base with perforated sheet across canister floor: N/A
• Wheels: 4? Flat Caster
• US/CSA Approved: Yes
• Decibel Reading: 88 d B(A) (@9.8ft)
• Machine weight: 134kgs/296Lbs
• Shipping weight: 165kgs/364Lbs
• Assembled Dimensions (L x W x H): 46? x 27? x 79? | 1178x690x2025mm

Product Features

• Powerful 1 HP, 120V heavy-duty TEFC motor and solid construction to effectively handle the collection of wood chips and sawdust
• 700 CFM air suction capacity
• Aluminum impeller is precision balanced and designed for maximum air flow performance
• Paddle switch with removable safety key
• Washable 1 Micron upper felt dust bag for optimal air flow efficiency and reusable clear plastic lower dust bags (3)
• Sturdy base with 4 swivel casters and handle for maneuverability
• 4” diameter inlet port
• 1 Micron canister filter, offering optimum air flow efficiency

• Powerful 3 HP, 240V TEFC motor
• Superior dust collection and air filtration
• Cyclone action separates heavy particles from the fine particles and drops them into steel drum
• Fine dust particles are collected in the 1 Micron canister filter with heavy-duty clear plastic bag
• 54 Gallon steel drum with quick release handle and castor wheels for easy disposal
• Manual crank handle for easy cleaning the inside of the canister filter
• Radio frequency remote control
• Complete with 4 locking caster wheels for portability

• Powerful 2 HP, 240V TEFC motor
• Superior dust collection and air filtration
• Cyclone action separates heavy particles from the fine particles and drops them into steel drum
• Fine dust particles are collected in the 1 Micron canister filter with heavy-duty clear plastic bag
• 29 Gallon steel drum with quick release handle and castor wheels for easy disposal
• Manual crank handle for easy cleaning the inside of the canister filter
• Radio frequency remote control
• Complete with 4 locking caster wheels for portability

• Powerful 1.5 HP, 120V TEFC motor
• Superior dust collection and air filtration
• Cyclone action separates heavy particles from the fine particles and drops them into steel drum
• Fine dust particles are collected in the 1 Micron canister filter with heavy-duty clear plastic bag
• 29 Gallon steel drum with quick release handle and castor wheels for easy disposal
• Manual crank handle for easy cleaning the inside of the canister filter
• Radio frequency remote control
• Complete with 4 locking caster wheels for portability
