B-302-PKG Pro-Tools Hydraulic Tube and Pipe Bender 302
  • SKU: B-302-PKG

Pro-Tools Hydraulic Tube and Pipe Bender 302 "One-Shot" Series

$1,972.95

Specs

Round Tube

  • Minimum Outside Diameter (OD): 1/2" (12.7 mm)
  • Maximum Outside Diamter (OD): 2" (50.8 mm)
  • Minimum Wall Thickness: Depends on Die (See Die Charts)
  • Maximum Wall Thickness: 0.134"

Pipe

  • Minimum Size: NPS 1/4 (DN 8)
  • Maximum Size: NPS 1-1/2 (DN 35)
  • Note: Our benders are rated for bending mild steel Schedule 40 Pipe. For other materials or Schedules, contact for details.

Square Tube

  • Minimum Size: 1/2" (12.7 mm)
  • Maximum Size: 1-1/2" (38.1 mm)
  • Minimum Wall Thickness: 0.065" (1.7 mm)
  • Maximum Wall Thickness: 0.125" (3.2 mm)

Other Specifications

  • Minimum Centerline Radius (CLR): Approx. 3 x OD (See Die Charts for details.)
  • Maximum Centerline Radius (CLR): 7" (177.8 mm)
  • Maximum Degree of Bend: 90 degrees, after springback

Features

  • Perfect for production applications
  • Adjustable stop included-set it once and create as many parts as you need
  • Bend up to 2", 0.134" tubing or NPS 1-1/2 pipe without any effort!
  • 100% Designed, Machined, and Assembled in the USA!
  • Bend up to 90 degrees, after springback, in one stroke of the cylinder
  • Designed for a lifetime of constant use
  • Forms quality, repeatable bends (less than 10% distortion in most cases)
  • Creates 90-degree bends in less than 30 seconds
  • Tooling changes in less than 60 seconds
  • All parts are CNC-machined for accuracy
  • Full selection of over 300 dies

Includes

  • One-Shot Tube and Pipe Bender
  • 16" x 17" Aluminum Table
  • Follow Bar Support Bar
  • Adjustable Stop
  • Stand
  • 15-Ton American-Made Hydraulic Cylinder
  • 10,000 PSI American-Made Air/Hydraulic Pump
  • Full Pin Set
  • Tensioning Bolt

Warranty

Our One-Shot Bender comes with a 1-year warranty against manufacturing defects. For full details on warranty and returns, see our full warranty policy.

Resources

Lead Time

Lead times vary by product. Many orders can ship out within a few days, but to make sure we offer our highest quality, some items our made-to-order. We never want to lose your business over lead time, so contact us if you need something ASAP.
