B-105-BRT-PKG Pro-Tools Hydraulic Tube and Pipe Bender 105 Series (Brute)
  • SKU: B-105-BRT-PKG

Pro-Tools Hydraulic Tube and Pipe Bender 105 Series (Brute)



Round Tube

  • Minimum Outside Diameter (OD): 1/2" (12.7 mm)
  • Maximum Outside Diamter (OD): 2-1/2" (63.5 mm)
  • Minimum Wall Thickness: Depends on Die (See Die Charts)
  • Maximum Wall Thickness: 0.134" (3.4 mm)


  • Minimum Size: NPS 1/4 (DN 8)
  • Maximum Size: NPS 2 (DN 50)
  • Note: Our benders are rated for bending mild steel Schedule 40 Pipe. For other materials or Schedules, contact for details.

Square Tube

  • Minimum Size: 3/4" (19.1 mm)
  • Maximum Size: 1-1/2" (38.1 mm)
  • Minimum Wall Thickness: 0.065" (1.7 mm)
  • Maximum Wall Thickness: 0.125" (3.2 mm)

Other Specifications

  • Minimum Centerline Radius (CLR): Approx. 3 x OD (See Die Charts for details.)
  • Maximum Centerline Radius (CLR): 7" (177.8 mm)
  • Maximum Degree of Bend: 180 degrees, depending on the die


  • Great for custom fabrication applications
  • Bend up to 2-1/2", 0.134" tubing or NPS 1-1/2 pipe with no effort!
  • 100% Designed, Machined, and Assembled in the USA!
  • The world's only true anti-springback system
  • Designed for a lifetime of constant use
  • Forms quality, repeatable bends (less than 10% distortion in most cases)
  • Creates 180-degree bends in less than 2 minutes (requires appropriate die)
  • Tooling changes in less than 30 seconds
  • All parts are CNC-machined for accuracy
  • Industrial-strength 1”-thick arms
  • Full selection of over 300 dies


  • Brute Tube and Pipe Bender
  • Built-in Degree Ring
  • 15-Ton American-Made Hydraulic Cylinder
  • 10,000 PSI American-Made Air/Hydraulic Pump with Hose
  • Stand
  • Full Pin Set
  • Tensioning Bolt


Our Brute Bender comes with a 1-year warranty against manufacturing defects. For full details on warranty and returns, see our full warranty policy.


Lead Time

Lead times vary by product. Many orders can ship out within a few days, but to make sure we offer our highest quality, some items our made-to-order. We never want to lose your business over lead time, so contact us if you need something ASAP.
