Powerful Tube Belt Sander to process even larger stainless steel pipes
Large wrap angle of 270° for seamless surfaces and quick work progress
Metabo Long-life motor with patented dust protection for long service life
Vario-Tacho-Constamatic (VTC)-Full Wave Electronics with Thumbwheel: for working at customized speeds to suit the application material and speeds that remain almost constant, even under load
Rubberized drive roller: reduces slipping of the sanding belt
Tool-free change of sanding belt and adjustable belt guide
Overload protection: protects the motor from overheating
Electronic soft start for smooth start-up
Restart protection: prevents unintentional start-up after power supply interruption
Auto-stop carbon brushes to protect the motor
The machine shown may differ in equipment and technical details depending on the configuration. Kindly pay attention to delivery scope and product description. Accessories included only if listed in the delivery scope.
Technical Data
Parameters:
Rated input power: 1550 W
Amps: 13.5 AMPS
Output power: 940 W
Belt speed in idle: 1650 - 5500 ft/min
Dimensions of sanding belt: 1 1/2 x 30 "
Maximum pipe diameter: 7.1 "
Wrap angle: 270 °
Weight (without power cable): 7.5 lbs
Cable length: 9.84 "
Vibration:
Surface grinding: 2.5 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission:
Sound pressure level: 94 dB(A)
Sound power level (LwA): 105 dB(A)
Uncertainty of measurement K: 3 dB(A)
Scope of Delivery
Side Handle
10 Sanding belts zirconia (40x760 mm; P80)
2 Sanding belts Pyramid (40x760 mm; P280/A65)
2 Sanding belts Pyramid (40x760 mm; P400/A45)
2 Sanding belts Pyramid (40x760 mm; P600/A30)
2 Sanding belts Pyramid (40x760 mm; P1200/A16)
3 Fleece belts (40x760mm medium)
Metal carrying case
