Long grinding spindle - ideal for working in hard to reach places
Spindle lock for simple change of tools
Cast aluminum bearing flange for long life of the machine
Vario- (VC)-Full wave electronics for working at customized speeds to suit the application materials, and speeds that remain almost constant even under load
Thumbwheel for speed preselection
Electronic safety shutdown of the motor for safe working in case the tool stops unexpectedly
Restart protection: prevents unintentional start-up after power supply interruption
Electronic overload protection for long service life
Precise collar for stationary use
Removable protective rubber cap for comfortable and safe working
Slim housing for ideal handling
Precision collet for precise concentricity
Long-life motor with patented dust protection for long service life
The machine shown may differ in equipment and technical details depending on the configuration. Kindly pay attention to delivery scope and product description. Accessories included only if listed in the delivery scope
Technical Data:
Parameters:
No-load speed: 10000 - 30500 RPM
Amps: 6.4 AMPS
Rated input power: 710 W
Output power: 430 W
Revolutions at rated load: 24000 RPM
Collar diameter: 1 11/16 "
Collet chuck bore: 1/4 "
Weight (without power cable): 3.5 lbs
Cable length: 9 ft
Vibration:
Grind surface (up to Ø 25 mm): 5.6 m/s²
Uncertainty of measurement K: 1.5 m/s²
Grind surface (up to Ø 50 mm): 16.9 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission:
Sound pressure level: 80 dB(A)
Sound power level (LwA): 91 dB(A)
Uncertainty of measurement K: 3 dB(A)
Scope of Delivery:
Collet 1/4“
Protective rubber cap
1 open-end wrench
