GXR Pipe notching module N09
  • SKU: 99001001110
  • Availability: in stock Many in stock Out of stock You can purchase this product but it's out of stock

GXR Pipe notching module N09

$2,990.95
Shipping calculated at checkout.
Radius grinding unit

Radius grinding module for exact-fit grinding of pipe, profiles and flat materials


  • For precisely cutting radii (with a diameter from 5/8 [16] to 3-1/2 [90] in[mm]) on pipes and profiles.
  • Contact rollers in standard sizes are available as options
  • Optional length stop for production applications
  • Integrated depth stop
  • Optional combination with GX 75 (2H) belt grinders
  • Independent angle settings possible up to 90˚
INCLUDES
  • 1 Contact roller 1-11/16 in [42.4 mm] dia.
  • 1 Contact roller 1-7/8 in [48.3 mm] dia.
  • 1 Grinding belt 75 x 2250 mm (36 grit R)
Technical Data
Pipes up to Ø 3/4 [16] - 3 [75] in[mm]
Belt dimension 3 [75] x 88-1/2 [2,250] in[mm]
Max. dimension of profile/flat material 3 [75] x 3 [75] in[mm]
Weight 119.05 [54] lbs[kg]
