Using the highest quality sub-micrograin carbide these bits have a special proprietary edge processing system featuring a super high polished cutting edge with a unique “mirror finish” resulting in clean cuts, less chance for chip re-welding, a superior surface finish and a longer tool life. Right hand helix right hand cut.
Specifically designed for a variety CNC machining applications excellent for cutting:
|
|
Ideal for industrial applications our spiral ‘O’ flute router bits are manufactured using innovative techniques and materials that yield superior results with each cut and help make aluminum projects less labor-intensive.
Warning: Never attempt to cut ferrous metals with these bits.
Inspect cut quality adjust feed / speed accordingly.
For optimal results and extended tool life use mist lubricant system or air cooling.
Maximum RPM:‚ 35,000
Router collet reduce‚‚r‚ RB-102‚ (1/4 to 1/8) available for 1/8 shank bits.
Vectric and Fusion 360 compatible tool files for 51406 available for download,‚ click here.
Direction | Up-Cut |
---|---|
(D) Diameter | 1/8 |
(B) Cutting Height | 5/16 |
(d) Shank | 1/8 |
Overall Length (L) | 1-1/2 |
Flutes | 1 |
