Heavy-duty cast-iron table and extension tables are double ground for accuracy and finish
Riving knife system for maximum operator safety
Table has “T” slots for miter gauge and beveled front edge
Magnetic safety switch
Large 8" diameter chromed handwheels with center locking knobs
Comes with 10" x 40 tooth carbide tipped saw blade, cast-iron miter gauge, standard and dado inserts, push stick storage hooks and hex. keys
50" Max rip capacity
Specification
MODELKC-10KX/U50
BLADE DIAMETER10"
BLADE TILTSLeft
DEPTH OF CUT AT 45°2-3/16"
MAXIMUM DEPTH OF CUT AT 90˚3-1/8"
SLIDING TABLE SIZE WITH EXTENSIONS40" x 27"
DIAMETER OF ARBOR5/8"
ARBOR SPEED (RPM)3,850
MOTOR2.5 HP, 9.6 Amp.
VOLTAGE230V, 1 phase, 60 Hz
WEIGHT410 lbs
UPC7 72995 01493 4
Additional Shipping Charges will Apply, Your order will be processed once rate is calculated
Service Manual
Instruction Manual
Spec Sheet
